20-1200 Series Hydrogen Pressure Regulator

20-1200 Series lightweight, aluminum constructed preset regulator offers an integrated 10 micron filter designed for hydrogen service. NGV 3.1 and TUV batch approved for onboard hydrogen fuel cell vehicles. Excellent choice for other OEM applications.

Pressure Rating: Maximum Inlet Pressure: 5100 psig / 351 bar (Aluminum body) – 10,200 psig / 702 bar (Stainless steel body)
Maximum Outlet Pressure: 450 psig / 31.0 bar

Body Material: Aluminum 6061-T6 with Electroless Nickel Plating, 316 Stainless Steel

Seat Material: Vespel®

O-Rings: Buna-N

Main Valve Material: 316 Stainless Steel

Sensor Material: Aluminum 6061-T6

10 Micron Filter: 316 Stainless Steel

Remaining Parts: 300 Series Stainless Steel, Teflon®, 18-8 Stainless Steel

Operating Temperature: -30°F to 165°F / -34°C to 74°C

Port Size & Type: Inlet & Outlet Port Type: SAE, NPTF
Inlet & Outlet Port Size
1/4 Inlet, 1/4 Outlet, 1/4 Gauge
3/8 Inlet, 1/2 Outlet, 3/8 Gauge
3/8 Inlet, 3/8 Outlet, 1/4 Gauge
